2SD882P D882P NPN Pwr Transistor by Shenzhen Jingdao Electronic

2SD882P D882P NPN Pwr Transistor by Shenzhen Jingdao Electronic.

DESCRIPTION
The 2SD882 is NPN silicon transistor suited for the output stage of 3 watts  audio  amplifier,  voltage  regulator,  DC-DC  converter  and  relay  driver.

Similar Part:
NTE184

PINOUT
1:  Emitter
2:  Collector: connected to mounting plane
3:  Base

FEATURES
•  Low   saturation   voltage
    VCE(sat) = 0.5 V MAX. (IC = −2 A, IB = 0.2 A)
•  Excellent   hFE linearity and high hFE hFE = 60 to 400 (VCE = 2 V, IC = 1 A)
•  Less cramping space required due to small and thin package and reducing the trouble for attachment to a radiator.
    No insulator bushing required.

ABSOLUTE MAXIMUM  RATINGS
Maximum Temperature
   Storage Temperature −55 to +150°C
   Junction   Temperature 150°C
Maximum Maximum Power Dissipations
   Total Power Dissipation (TA = 25°C) 1.0 W
   Total Power Dissipation (TC = 25°C) 10 W
Maximum Voltages and Currents (TA = 25°C)
   VCBOCollector to Base Voltage 40 V
   VCEOCollector to Emitter Voltage 30 V
   VEBOEmitter to Base Voltage 5.0 V
   IC(DC)Collector Current (DC) 3.0 A
   IC(pulse) Collector Current (pulse) 7.0 A
   Note Pulse Test PW ≤ 350 μs, Duty Cycle ≤ 2%
