Product Overview
1.5KE10A TVS Silicon Transient Suppressor by Littelfuse.
Similar Part:
NTE4910
Features:
Surge Clamping
DO-201 Package
TVS Diode
Transient Overvoltage Suppressor Unidirectional
Voltage - Reverse Standoff (Typ) = 8.55V
Voltage - Breakdown (Min) = 9.5V
Voltage - Clamping (Max) @ Ipp = 14.5V
Current - Peak Pulse (10/1000µs) = 104.8A
Power - Peak Pulse = 1500W (1.5kW)
Power Line Protection = No
Operating Temperature = -55°C ~ 175°C (TJ)
