Product Overview
10mm Dia. IP40 Anti-Vandal Switch SPST-NO by CIT Relay and Switch (GHNDSBX).
Made in USA.
Specs:
Momentary Switch
Panel Mount, Front Mounting Type
Anti-Vandal Type
SPST-NO Circuit
Off-Mom Switch Function
2A (DC) Current Rating
48V Voltage Rating
Round, Button Actuator Type
Silver Color - Actuator/Cap
Solder Lug Termination Style
IP40 Ingress Protection
10mm Panel Cutout Dimensions
-25C ~ 55C Operating Temperature
100,000 Cycles Mechanical Life
50,000 Cycles Electrical Life
