CIT Relay

12VDC, 25A SPDT Relay by CIT Relay (A161CS12VDC.64)

12VDC, 25A SPDT Relay by CIT Relay (A161CS12VDC.64)

Regular price $2.25 USD
Regular price Sale price $2.25 USD
Sale Sold out
Shipping calculated at checkout.

Quantity Available: 0

12VDC, 25A SPDT Relay by CIT Relay (A161CS12VDC.64).
Automotive Relay.

Coil Type: Non-Latching
Coil Current: 53.3 mA
Coil Voltage: 12VDC
Contact Form: SPDT (1 Form C)
Contact Rating (Current): 25 A
Switching Voltage: 20VDC - Max
Must Operate Voltage: 8.4 VDC
Must Release Voltage: 1.2 VDC
Operate Time: 10 ms
Release Time: 5 ms
Features: Sealed - Fully
Operating Temperature: -40°C ~ 105°C
Contact Material: Silver Tin Oxide Indium Oxide (AgSnOInO)
Coil Power: 640mW
Coil Resistance: 225 Ohms
RoHS Status: RoHS Compliant
